Q-Shield - C- Smart Connected Wrench

Q-SHIELD 350-C

6152210370

Q-Shield 350-C-Digital Smart Wrench Wi-Fi-35 to 350 Nm

Package Dimensions 82 x 20.5 x 16 cm

Package Weight 5.6 kg

Add to Quote

Find spare parts and informationVisit ServiceLink

Q-SHIELD 350-C

Desoutter Q-Shield 350-C-Digital Smart Wrench is designed to error proof your operation, from manual tightening operation, torque checking or quality check operation, with or without full reporting. The device features 35Nm to 350Nm, a long life Li-ion battery (3.5Ah), gyroscope, Yield detection and a double bridge strain gauge to provide full traceability, irrespective of the operator or process.

Country of origin is IT. Customs tariff is 82041100

Benefits

Accurate transducer ensuring the quality of each tightening and reducing your potential warranty costs.

Perfect for hard-to-access applications where other tools cannot be used, open or closed crowfoot, with high accuracy (+/-1%)

Direct operator feedback with the LED display and vibration capability reducing your cycle time and potential quality costs.

Wi-Fi communication with Connect (Industrial hub) - open for any industrial communication

Easily programmable using CVI CONFIG software, providing comprehensive asset management capability to lower your operating costs.

For e-link version, trackers are powered by the wrench providing ultimate convenience: No cables or charging of tags required

For e-link version, integrated trackers with Real-Time Location System provide unmatched precision and reduced risk of errors.

Features

Precise transducer

High torque accuracy (+/-1%)

High angle resolution (1% from 3°/s to 250°/s angular speed (2,5% from 1,2° to 3°/s))

Integrated within Desoutter Ecosystem thanks to the Connect

CVI suite available

For e-link version, no cables or charging of tags required
